2005 crd thermostat upgrade?

MiloHunter

New Member
Joined
Jan 21, 2022
Messages
6
Reaction score
3
Any ideas on running a 190 degree thermostat? Mines crapping out and am looking for good replacement. Thanks in advance for any input.


LibertyTC

Well-Known Member
Staff member
Moderator
Joined
Oct 24, 2008
Messages
8,689
Reaction score
1,282
Location
B.C. Canada
Welcome to the forums.
I'd recommend using the Mopar replacement thermostat only & it's part # 05142601AA. (hopefully it's still available?)
Gasket is: 05066806AA
The 05 CRD thermostat & complete parts fiche/ diagrams is here from page 90: http://www.colorado4wheel.com/manuals/Jeep/KJ/05kj_PARTS_FICHE.pdf
I'll move this to the CRD section.


turblediesel

memberable
Joined
May 31, 2015
Messages
2,994
Reaction score
625
Location
Alaska
Look into TURBO-DIESEL-FREAK's aftermarket thermostat housing which allows thermostats to be swapped without buying the $150 oem thermostat housing. There's also a modification to the original housing that needs a couple of turned parts and some welding.

I don't remember what temp thermostat works best for the CRD but 190 seems low.


mrhemi

Full Access Member
Joined
Jan 9, 2014
Messages
34
Reaction score
1
Location
Canada
I have been running both of my CRD's with the 203 deg.f thermostats supplied with the HDS 001 aftermarket housings. One of them has over 120000 miles with that in it. Works great from sub-zero to 100 plus temps. You can also eliminate the stupid viscous heater when you utilize the higher temperature.


MiloHunter

New Member
Joined
Jan 21, 2022
Messages
6
Reaction score
3
I have been running both of my CRD's with the 203 deg.f thermostats supplied with the HDS 001 aftermarket housings. One of them has over 120000 miles with that in it. Works great from sub-zero to 100 plus temps. You can also eliminate the stupid viscous heater when you utilize the higher temperature.
Where can I get one?


MiloHunter

New Member
Joined
Jan 21, 2022
Messages
6
Reaction score
3
Look into TURBO-DIESEL-FREAK's aftermarket thermostat housing which allows thermostats to be swapped without buying the $150 oem thermostat housing. There's also a modification to the original housing that needs a couple of turned parts and some welding.

I don't remember what temp thermostat works best for the CRD but 190 seems low.
Thanks for the info!


JMichael2006

New Member
Joined
Oct 11, 2021
Messages
26
Reaction score
24
The thermostat on my 06 CRD failed at 85K, but failed open so I installed a 192+ from a 1983 Renault Alliance. They go inside the upper hose and still working perfectly at 240K. I removed the OEM units guts when I replaced the timing belt (2nd) at 100K. I will go with TDF's unit next belt go-round because I plan on doing a bunch of other upgrades.


MiloHunter

New Member
Joined
Jan 21, 2022
Messages
6
Reaction score
3
I have been running both of my CRD's with the 203 deg.f thermostats supplied with the HDS 001 aftermarket housings. One of them has over 120000 miles with that in it. Works great from sub-zero to 100 plus temps. You can also eliminate the stupid viscous heater when you utilize the higher temperature.
Where do I contact this company?


turblediesel

memberable
Joined
May 31, 2015
Messages
2,994
Reaction score
625
Location
Alaska
TURBO-DIESEL-FREAK is on LOSTJEEPS forum mostly but he's here as well so try giving him a PM or email.
